ASSEMBLY AND OPERATION
APPLICATIONS
⅜ Use as a drill
Drilling of soft steel, wood, plastic and aluminum materials.
⅜ Use as a screwdriver
Tightening and loosening of machine screws, wood screws and tapping screws.
REMOVAL AND INSTALLATION METHOD OF BATTERY
⅜ How to install the battery.
Align the battery with the groove in tool handle and slip it into place.
Always insert it all the way until it locks in place with a little click, If not, it may accidentally
fall out of the tool, causing injury to you or someone around you (Fig. 3).
⅜ How to remove the battery.
Withdraw battery from the tool handle while pressing the latch (1 pc. or 2 pcs) of the
battery (Fig. 3).
<DS12DVF3> <DS14DVF3 and DS18DVF3>
CHARGING METHOD
NOTE: Before plugging into the receptacle, make sure the following points.
⅜ The power source voltage is stated on the nameplate.
⅜ The cord is not damaged.
WARNING: Do not charge at voltage higher than indicated on the nameplate.
If charged at voltage higher than indicated on the nameplate, the
charger will burn up.
Fig. 3
Latch
Handle
Insert
Battery
Latch
Push
Handle
Pull out
Insert
Battery
Push
Pull out
