14
Plastic base plate (optional accessory)
Use the plastic base plate when cutting decorative veneers,
plastics, etc. It protects sensitive surfaces from damage. To
replace the base plate, remove the four screws.
Rip fence (optional accessory)
When cutting widths of under 150 mm (5 - 29/32”) repeat-
edly, use of the rip fence (guide rule) will assure fast, clean,
straight cuts. To install it, loosen the bolt on the front of the
base. Slip in the rip fence and secure the bolt.
Circular guide (optional accessory)
Use of the circular guide insures clean, smooth cutting of cir-
cles under 200 mm (7 - 7/8”) in radius. Insert the pin through
the center hole and secure it with the threaded knob. Move
the base of the tool forward fully. Then install the circular
guide on the base in the same manner as the rip fence
(guide rule).
Vacuum head (optional accessory)
The vacuum head is recommended to perform clean cutting
operations. Install the plastic cover on the tool by fitting it into
the notches in the tool.
1. Screw
2. Plastic base plate
1
2
002736
1. Hex wrench
2. Bolt
3. Rip fence (Guide rule)
1
2
3
002738
1. Threaded knob
2. Circular guide
3. Pin
1
2
3
002739
1. Notches
2. Base
3. Plastic cover
1
2
3
002740
