OM-2233 Page 43
Figure 11-3.Panel, Rear w/Components
202 397-E
. Hardware is common and not available unless listed.
2
600
1
4
5
3
Figure 11-3. Panel, Rear w/Components (Figure 11-1 Item 2)
Quantity
Description
Part
No.
Dia.
Mkgs.
Item
No.
1 194242 Panel, Front/Rear 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 206053 Panel, Rear Lower 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 195646 Panel, Rear Upper 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 201155 Bushing, Strain Relief .450/.709 Id X1.068 Mtg Hole 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 207253 Plug, Gas Fitting 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
600 198245 Nut, Conduit .750 Npt Pld 1.388 Od X .150 Thk 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
+When ordering a component originally displaying a precautionary label, the label should also be ordered.
To maintain the factory original performance of your equipment, use only Manufacturer’s Suggested
Replacement Parts. Model and serial number required when ordering parts from your local distributor.
