24- ENG
ACCESSORIES
Since accessories, other than those offered by PORTER-CABLE, have
not been tested with this product, use of such accessories with this tool could be haz-
ardous. To reduce the risk of injury, only PORTER-CABLE recommended accessories
should be used with this product.
A complete line of accessories is available from your PORTER-CABLE Factory Service
CenteroraPORTERCABLEAuthorizedWarrantyServiceCenter.PleasevisitourWeb
Site www.deltaportercable.com for a catalog or for the name of your nearest supplier.
TROUBLESHOOTING
Risk of Unsafe Operation. Unit cycles automatically when
power is on. When servicing, you may be exposed to voltage sources,
compressed air, or moving parts. Before servicing unit unplug or disconnect
electrical supply to the air compressor, bleed tank of pressure, and allow the
air compressor to cool.
PROBLEM CAUSE CORRECTION
Excessive
tank pressure
- safety valve
pops off
Pressure switch does
not shut off motor when
compressor reaches
"cut-out" pressure.
Move Auto/Off lever to the "Off"
position, if the unit does not shut off
contact a Trained Service Technician.
Pressure switch "cut-
out" too high.
Contact a Trained Service Technician.
Air leaks at
fittings
Tube fittings are not
tight enough.
Tighten fittings where air can be
heard escaping. Check fittings
with soapy water solution. DO
NOT OVER TIGHTEN.
Air leaks at
or inside
check valve
Check valve seat
damaged.
A defective check valve results in
a constant air leak at the pressure
release valve when there is pressure in
the tank and the compressor is shut
off. Replace check valve. Refer the To
Replace or Clean Check Valve in
the Service and Adjustments section.
Air leaks at
pressure switch
release valve
Defective pressure
switch release valve.
Contact a Trained Service Technician.
Air leaks in air
tank or at air
tank welds
Defective air tank. Air tank must be replaced.
Do not repair the leak.
Risk of bursting.
Do not drill into, weld or otherwise
modify air tank or it will weaken. The
tank can rupture or explode.
Air leaks
between head
and valve plate
Leaking seal. Contact a Trained Service Technician.
