19
Operation
INITIAL PROGRAMMING OF CONSOLE COMPUTER
(CONTINUED)
6. To display SPEED, momentarily depress the key labeled:
7. To display VOL/MIN., momentarily depress the key labeled:
8. To display AREA/HOUR, momentarily depress key labeled: This is an actual calculation of AREA/
HOUR at the present speed you are going. It is not an average over time.
9. To display TIP MONITOR fault, momentarily depress the key labeled: See TIP MONITOR manual
for more detailed discussion. (Purchase the TIP MONITOR option if this function is desired.)
10. To display US, SI or TU and SPI or SP2 after being selected depress: These selections will be
alternately displayed.
SELF TEST FEATURE
SELF-TEST allows speed simulation for testing the system while the vehicle is not moving. Enter the simulated
operating speed in the key labeled: If 6 MPH (10 km/h) is desired, enter 6.0 (10.0). Verify speed by de-
pressing key labeled: SPEED
The SELF-TEST speed will clear itself when motion of vehicle is detected by the Speed Sensor. A SPEED CAL
Value of 900 (230) or greater is recommended when operating in this mode.
SEQUENCE TO ACTIVATE DATA-LOCK*
1. Depress for 5 seconds, NEW CODE message will appear.
2. Enter 4 digit code within 15 seconds.
EXAMPLE: For 1085, depress and
SEQUENCE TO CHANGE DATA-LOCK
1. Depress for 5 seconds, OLD CODE message will appear.
2. Enter 4 digit OLD CODE within 15 seconds.
EXAMPLE: depress and
NEW CODE message will appear. Enter 4 digit code within 15 seconds.
EXAMPLE: For 1285, depress and
