Introduction
SPECIFICATIONS
WEIGHTS AND DIMENSIONS
Length 112" (285 cm)
Width 61" (155 cm) Width With Booms Down 230" (584 cm)
Height 50" (127 cm) Height With Booms Up 126" (320 cm)
Wheel Base 60" (152 cm)
Weight Empty 1200 lb (544 kg) Weight Loaded 2500 lb (1134 kg)
SOUND LEVEL AT 3400 RPM
At ear level 88 dB
At 3 ft. (0.914 m) 84 dB
At 30 ft (9.14 m) 72 dB
ENGINE
Make Kohler
Model# Command CH25S
Type / Spec# PA-68666
Horsepower 25 hp (18.6 kW)
Fuel Unleaded 87 Octane Gasoline Minimum
Cooling System Air cooled
Lubrication System Full pressure
Alternator 25 Amp
WHEELS & TIRE Front (2) 20 x 1000 x 10 Multi-rib 20 psi (1.4 bar)
Rear (2) 24 x 1300 x 12 Super Soft 18 psi (1.3 bar)
Ground Pressure: 8.2 psi with 160 gallons
SPEED
Forward Speed 0-10 m.p.h. (0 - 16 kph)
Reverse Speed 0-3 m.p.h. (0-5 kph)
BATTERY Automotive type 24F-12 volt
BCI Group Size 24
Cold Cranking Amps 575 minimum
Ground Terminal Polarity Negative (-)
Maximum Length 10.25" (26 cm)
Maximum Width 6.88" (17 cm)
Maximum Height 10" (25 cm)
FLUID CAPACITY
Crankcase Oil 2.1 quart (2 liters) with filter
Fuel 5 gallon (19 liters)
Hydraulic Fluid 5 gallon (19 liters)
Grade of Fluid SAE 10W-40 API Service SJ or higher motor oil
OPTIONAL SPRAY EQUIPMENT
33-216 Battery 24F-12 Volt 14-100 Super Boom 20' (6 meter) Long
14-315 Fresh Water Wash Tank 10-300 18' Terrain Following Boom
14-319 Hose Reel Mounting Frame 15-493 Auto-Boom 18' (5.5 m) Long
15-571 15' Tri-Section Electric Lift Star Shield Boom 15-577 18' Manual Lift Boom
15-572 15' Dual Section Electric Lift Star Shield Boom 14-481 440 Spray System (1602HD)
15-573 15' Manual Lift Star Shield Boom 14-483 203 Spray System (1604HD)
16-856 Tank Rinsing System
16-129 Hose Reel 200' (61 m) capacity (to be used with 14-319) 14-312 Speedometer Kit
16-906 Hose Reel 12 volt electric rewind 200' (61 m) 14-283 Foam Marker System (Dealer Installed)
capacity (to be used with 14-319) 14-285 Foam Marker System (Factory Installed)
