Wilton 3410 Saw User Manual



27
50 5710551 Bearing pin 2
51 5710561 Eccentric shaft assy. 2
51-1 5517504 Center shaft assy. 2
52 5710571 Brush 1
53 5710581 Hex nut 3/8x24 4
54A 5710591 Oil plug 1
55 5710611 Phillips screw 1/4x3/8 2
56 5710621 Vertical cutting plate 1
57 5710631 Blade adjustable sear - rear 1
58 5710641 Adjustable bracket bar - rear 1
59 5710651 SHCS 5/16x1-1/8 2
60 5710661 Vertical cutting plate (small) 1
61 5710671 Brush bracket 1
62 5710681 Nozzle bracket 1
62-1 5517505 Valve 1
62-2 5517506 Nozzle cock 1
63 5710691 Blade guard 1
65 5710721 Saw bow (arm)-rounded style 1
5711821 Saw bow (arm)-square style
66 5710731 HH screw 5/16x2-1/2 2
67 5710741 Thumb screw 3
67A 5711561 Washer 1/4 2
68 5710751 Blade cover assy early style 1
5711811 Blade cover assy later style
85 5710941 Washer 5/16 6
87 5710961 Collar 1
93 5711031 Spring washer 5/16 13
93-1 5517507 Adj. Screw 1/4x3/8 2
94 5711041 Nut 5/16 4
98 5711081 Set screw 1/4x1/4 2
103 5711141 Washer 5/16 2
116 5711281 Hex nut 5/16 1
122 5711351 Key 5mm 1
141 5711561 Washer 1/4 8
142 5711571 Screw 3/16x1/4 2
145 5711391 Cooling fan cover 1
147 5711431 Capacitor cover 1
148 5711471 Capacitor 1
149 5711481 Cooling fan 1
150 5711841 Bushing 1
152 5710531A Blade guide assy left side 1
153 5710631A Blade guide assy right side 1
155 5711951 Rubber flap 1
156 5711251 Cord 1
158 5711991 C-clip 1
159 5710511A Cmplte gearbox 42mm bore 1
160 5711801 Cmplte gearbox 47mm bore 1
161 5517509 Block plate 1
162 5517510 Hex soc. screw 3/16x1/2 3
163 5517511 Bearing bushing 1
164 5517512 Key 6x20 1
165 5517513 HH screw 3/8x1 1
166 5517514 Spring washer 3/8 1
167 5517515 Washer 3/8x35x4 1
168 5517516 Top support 1
169 5517517 HH screw 3/8x1-1/2 2
170 5517518 Spring washer 3/8 2
171 5517519 Nut 3/8 2
172 5517508 HH screw 1/4x3/8 2
5711421 Junction box cvr (not shown) 1
1 5710011 Pulley cover 1
2 5710021 Motor pulley 1
4-1 5710041 HH screw 5/16X1 4
5 5710051 Motor 3/4 HP 115V 1PH 1
6 5710061 Motor mount plate assy. 1
7 5710071 HH screw 5/16x5/8 3
8 5710081 HH screw 5/16x1-1/4 1
9A 5710091 Tapping screw 6mmx20 4
10A 5710111 Gearbox cover 1
11A 5710121 Gearbox gasket 1
12 5710131 Trnsmsion gear 20mm bore 1
12 5711921 Trnsmsion gear 25mm bore
13 5710141 Ball bearing 6005 2
14 Saw Blade:
5632141 3/4 X .032 X 93" 8 TPI
5632151 3/4 X .032 X 93" 8 T STND 1
5632161 3/4 X .032 X 93" 14 TPI
15 5710161 Oil seal 20.42.7 1
5711881 Oil seal 25.47.7
16 5635271 Ball bearing 6004Z 1
5680391 Ball bearing 6005Z
17 5710181 Trnsmsion Shaft - 5/8 bore 1
5711931 Trnsmsion Shaft - 7/8 bore
18 5710191 Blade whl rear 20mm bore 1
5711831 Blade whl rear 25mm bore
19 5710211 Washer 3/8 1
21 5710231 Belt 3V-270 1
22 5710241 Worm pulley 1
23 5710251 Set screw 5/16x3/8 3
23-1 5517501 Set screw 5/16x3/4 1
25 9100451 Ball bearing 6003 1
26 5710281 Oil seal 17.35.7 1
27 5710291 Bearing bushing 1
28 5710311 Ball bearing 6003 2
29 5710321 Worm gear shaft 1
30 5710331 Snap ring 42mm 2
30 5711871 Snap ring 47mm
31 9052181 HH screw 5/16x1-1/2 2
32 5710351 Blade tension sliding plate 1
33 5710361 Sliding plate draw block 1
34 5710371 Blade wheel shaft - front 1
35 5710381 Bearing bushing 1
36 9100331 Ball bearing 6203 1
37 5710411 Switch actuator 1
38 5710421 Blade wheel - front 1
39 9100331 Ball bearing 6203 1
40 5710441 Phillips screw 1/4x1/2 4
41 5710451 HH screw 5/16x3/4 1
42 5710461 HH screw 1/4x1/2 7
42-1 5517502 Spring washer 1/4 1
42-2 5517503 Washer 1/4 1
43 5710471 Blade tension sliding guides 2
44 5710481 Blade tension adj. knob 1
45 5630601 Knob 2
46A 5710511 Transmission gearbox 42mm 1
5711861 Transmission gearbox 47mm
47 5710521 Adjustable bracket bar - front 1
48 5710531 Blade adjustable seat - front 1
49 5632831 Ball bearing 608ZZ 2
Qty.
Description
Part.no.
Ref.
no.
Parts List - Saw Head
Qty.
Description
Part.no.
Ref.
no.
