4
Cutting capacity
Blade speeds
Blade drive
Motor
Blade guides
Blade size
Blade wheels
Dimensions (LWH)
Weight
Wet cutting package
General
Specifications
The Wilton Models 3400 and 3410 cut-off band saws
are designed for high production cut-off work. Four cutting
speeds and a hydraulic feed control allows the efficient cut-
ting of virtually any material.
A removable table also allows the saw to function as a
vertical band saw.
7 in. (178mm) round bar stock or tubing
9 1/2 in. wide x 7 in. high (240 x 178mm) rectangular stock
12 in. wide x 1 in. high (305 x 25.4mm) flat stock
3 3/4 in. wide x 6 in. high (95.3 x 150mm) at 45 degree angle
The Model 3410 is equipped with an optional coolant
system which can greatly extend blade life and speed the cut-
ting of a variety of materials which are best cut with cutting
fluids and coolants.
The Model 3400 is not equipped with a coolant system.
However, the coolant system is available as an add-on kit for
customer installation.
1 gallon (4.4L) capacity tank with 3GPM (13L/M) pump -- Optional wet kit
Part No. 5635500 includes tank with baffle, pump 120V/240V, hoses,
flexible nozzle, shut-off valve and required electrics. This kit is delivered
installed on Model 3410 saws.
80, 130, 180 and 265 SFM -- belt selectable
Heat treated steel worm pinion driving a bronze
worm ring gear in an oil bath
3/4 HP, 1725 RPM, 115/230V, single phase, capacitor start
Side: Eccentric shaft with sealed ball bearings
Rear: Sealed ball bearing
3/4 x .032 x 93 in.
11 7/16 in. (280.56mm) diameter flanged cast iron
50 x 18 x 41 in. (1270 x 457 x 1041mm) in lowered position
275 lbs. (125kg)
Specifications:
9 1/2 x 10 in. (241 x 254mm)
Vertical saw operation
Table size (LW)
