SKU 47606 For technical questions, please call 1-800-444-3353. Page 2
Specications
Chuck Capacity 1 Inch
Power 120 V, 60 Hz, 1.13 HP, 850 Watts
Amperage 6.8 Peak Amps, 4.6 Working Amps
RPM 900
Blows per minute 3,200
Accessories: Break Point (Bull) Bit, Flat Head Chisel, Depth Rod, Lubricant,
Masonry Drill Bits (10mm, 9/16”, 7/8”), Extra Brushes, Blowmold Case
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instructions, operating
and maintenance procedures, parts list and diagram. Keep your invoice with this manual. Write
the invoice number on the inside of the front cover. Keep the manual and invoice in a safe and
dry place for future reference.
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be followed to reduce
the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
Keep work area clean. Cluttered areas invite injuries.
Observe work area conditions. Do not use machines or power tools in damp or wet locations.
Don’t expose to rain. Keep work area well lighted. Do not use electrically powered tools in the
presence of ammable gases or liquids.
Keep children away. Children must never be allowed in the work area. Do not let them handle
machines, tools, or extension cords.
Store idle equipment. When not in use, tools must be stored in a dry location to inhibit rust.
Always lock up tools and keep out of reach of children.
Use the right tool for the job. Do not attempt to force a small tool or attachment to do the
work of a larger industrial tool. There are certain applications for which this tool was designed.
It will do the job better and more safely at the rate for which it was intended. Do not modify this
tool and do not use this tool for a purpose for which it was not intended.
Dress properly. Do not wear loose clothing or jewelry as they can be caught in moving parts.
Protective, electrically nonconductive clothes and nonskid footwear are recommended when
working. Wear restrictive hair covering to contain long hair.
Use eye, face and ear protection. Always wear ANSI approved impact safety goggles. Wear
a full face shield if you are producing metal lings or wood chips. Wear an ANSI approved dust
mask or respirator when working around metal, wood, and chemical dusts and mists.
Do not overreach. Keep proper footing and balance at all times. Do not reach over or across
running machines.
Maintain tools with care. Keep tools sharp and clean for better and safer performance. Follow
instructions for lubricating and changing accessories. Inspect tool cords periodically and, if
1.
2.
3.
4.
5.
6.
7.
8.
9.
REV 03d; 05k
