SKU 47606 For technical questions, please call 1-800-444-3353. Page 9
Parts List
Part Description
1 O-ring
2 Steel Ball
3 Cylinder
4 Flat Pin
5 Striker
6 O-ring
706 Spring
7 Cone Gear
7D Steel Retaining Ring
511 Oil Bearing
8 Piston
9 Piston Pin
10 Connecting Rod
11 Needle Bearing
12 O-ring
13 O-ring
14 Oil Seal Cap
16 Nameplate
18 Bolt
19* Spring Washer
20 Cylinder Case
21 Cylinder Cap
22 Oil Seal
23 Washer
24 Ball Bearing
25 Urethane Ring
26 Plastic Duct
27 Front Cap
28 O-ring
29 Slider
30 Steel Ball
31 Guard Ring Sleeve
32 O-ring
33 O-ring
34 Second Striker
Part Description
35 Spring
36 Label
37 Small Cone Gear
38 Oil Seal
39 Bearing
40 Washer
41 Pull Board
42 Clutch Washer
43 Second Gear
44 Dish Form Spring
45 Specialty Nut
46 Bearing
47 Crankcase
48 Crankshaft
49 Steel Ball
303 Lifting Post
50 Bearing
52 Bearing Cap
53 Spring Washer
54 Bolt
55 First Gear
56 Needle Bearing
57* Gear Case
58* Bearing
60* Rotor
61* Tap Bolt
63 Inductor
64* Down Lead Spring
65* Bearing
66* Washer
67* Bolt
68* Brush Holder
69* Brush
70* Brush Cap
301 Retainer Ring
Part Description
302 Switch Handle
71* Air Bafe
72* Stator
74* Motor Casing
75* Bolt
76* Bottom Cap
77* Tap Bolt
78 Tap Bolt
79 Handle Cap
80 Handle Buff
85 Capacitor
86 Switch
89 Main Handle
90 Washer
91 Bolt
92 Tap Bolt
93** Cable
97 Cable Clamp
98** Cable Sheath
701 Knob
702 Spring
703 Steel Ball
704 Retainer Ring
705 Knob Seat
501 Dust Cap
503 Packing Carton
504 Drill Stop
505 Handle
506 Chuck Ring
507 Handle Clip
508 Handle Band
509 Square Toes Bolt
100* Motor Assembly
101** Cable Assembly
Replacement parts with asterisk are not available individually. You must purchase either the #100 Motor Assembly
or the #101 Cable Assembly.
* #100 Motor only sold as a replacement assembly.
** #101 Cable only sold as a replacement assembly.
