-30-
Model G0766 (Mfd. Since 07/15)
Spindle Turning Tips:
• When turning the lathe ON, stand away from
the path of the spinning workpiece until the
spindle reaches full speed and you can verify
that the workpiece will not come loose.
• Use the slowest speed when starting or stop-
ping the lathe.
• Select the right speed for the size of workpiece
that you are turning (refer to Figure 25 on
Page 26).
• Keep the turning tool on the tool rest the
ENTIRE time that it is in contact with the
workpiece.
• Learn the correct techniques for each tool
you will use. If you are unsure about how to
use the lathe tools, read books or magazines
about lathe techniques, and seek training
from experienced and knowledgeable lathe
users.
Faceplate Turning
Faceplate turning is when a workpiece is mounted
to the faceplate, which is then mounted to the
headstock spindle, as shown in Figure 36. This
type of turning is usually done with open-faced
workpieces like bowls or plates.
Figure 36. Typical faceplate turning operation.
Mounting Workpiece on Faceplate
1. Mark workpiece center in same manner as
described in Spindle Turning (see Page 28).
Note: Cut off corners of workpiece to make it
as close to "round" as possible, as described
in Spindle Turning, Step 5 (see Page 29).
Faceplate Turning
Figure 37. Typical attachment of faceplate to
workpiece.
2. Center faceplate on workpiece and attach it
(see Figure 37) with wood screws.
Eye injuries or respiratory problems can
occur while operating this tool. Wear per-
sonal protective equipment to reduce your
risk from these hazards.
