Page 2SKU 47158
For technical questions, please call 1-800-444-3353.
SPECIFICATIONS TABLE
Electrical Requirements 120 V / 6 0 Hz / 1/5 HP
2 Speed Ranges High: 100-2,000 RPM / Low: 100-1,000 RPM
Maximum Chuck Capacity 25/64” Drill Bit / 25/64” End Mill / 3/4” Face Mill
Maximum X Travel 9”
Maximum Y Travel 4”
Maximum Z Travel 8-1/2”
X, Y, Z Graduations .001” / Line
Table Size 9-3/8” x 5-3/8”
Table Slot 5/16” x 5/8”
Throat Depth 5-1/2”
Swing Diameter 11”
Base Size 10-1/8” x 9-3/8”
Spindle Stroke 1-3/16”
Spindle Taper MT2
Weight 103 Pounds
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, op-
erating, inspection, maintenance and cleaning procedures, parts list and
assembly diagram. Keep your invoice with this manual. Write the invoice
number on the inside of the front cover. Keep this manual and invoice in a safe
and dry place for future reference.
GENERAL SAFETY WARNINGS AND PRECAUTIONS
1. KEEP WORK AREA CLEAN AND DRY. Cluttered, damp, or wet work areas
invite injuries.
2. KEEP CHILDREN AWAY FROM WORK AREA. Do not allow children to handle
this product.
3. STORE IDLE EQUIPMENT. When not in use, tools and equipment should be
stored in a dry location to inhibit rust. Always lock up tools and equipment, and
keep out of reach of children.
4. DO NOT USE THIS PRODUCT IF UNDER THE INFLUENCE OF ALCOHOL OR
DRUGS. Read warning labels on prescriptions to determine if your judgement or
reflexes are impaired while taking drugs. If there is any doubt, do not attempt to
use this product.
