SKU 95004 For technical questions, please call 1-800-444-3353 PAGE 15
BASIC OPERATING INSTRUCTIONS
1. CAUTION! Always use safety equipment. Wear ANSI approved
safety impact eye goggles and heavy duty work gloves when oper-
ating the Jigsaw. Also, a dust mask and hearing protection must be
used for appropriate conditions.
2. IMPORTANT: Always secure the workpiece in place, using a vise or clamps (not
included).
3. Make sure the Power Switch (67) is in its “OFF” position and the Power Cord/
Plug (68) is unplugged from the electrical outlet.
4. If necessary, make adjustments to the depth of cut and angle of cut.
5. Once all adjustments are made, plug the Power Cord/Plug (68) into the nearest
120 volt, grounded, electrical outlet.
6. Position the Saw Blade (20) about 1/2” from the beginning cut line on the
workpiece. Do not allow the Saw Blade to come in contact with the workpiece.
7. Turn the Laser Switch (74) to its “ON” position, and align the laser beam with the
cut line on the workpiece. Note: Kerf will be centered on laser beam.
8. Squeeze the Power Switch (67) to turn on the Circular Saw. If operating the Saw
for an extended period of time, you may wish to depress the Switch Lock to
lock the Power Switch in its “ON” position.
9. Allow the Saw Blade (20) to rotate at full speed before slowly feeding it into
the workpiece.
10. Make sure to hold the Circular Saw firmly with both hands to avoid kickback.
Then, finish making the cut.
11. When finished, release the Power Switch (67) to stop the Circular Saw. Wait until
the Saw Blade (20) stops completely. Turn the Laser Switch (74) to its “OFF”
position. Then, remove the Circular Saw from the workpiece.
12. Make sure to store the Circular Saw in a clean, dry, safe location out of reach of
children and other unauthorized people.
