PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures, parts list and as-
sembly diagram. Keep your invoice with this manual. Write the invoice number
on the inside of the front cover. Keep this manual and invoice in a safe and dry
place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
1. Keep your work area clean and well lit. Cluttered benches and dark areas
invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operating a power tool.
Distractions can cause you to lose control. Protect others in the work area from
SKU 95004 For technical questions, please call 1-800-444-3353 PAGE 2
Item Description
Electrical Requirements 120 V / 60 Hz / 10 Amps / 5,000 RPM
Power Switch Type: Trigger Switch with Safety Thumb Lock
Power Cord Type: 18AWG x 2 C, SJT / 83-1/2” Long
Power Plug Type: 2-Prong, Polarized
Laser Specifications Output Power: 1MW / Wavelength: 650NM
Laser Class I / Required Battery Type: “AAA” (Qty. 2 Included)
Saw Blade Requirements 7-1/4” Diameter (Included) / Minimum 5,000 RPM Rating
Maximum Cutting Depth 2-1/2” @ 90° / 1-3/4” @ 45°
Spindle Diameter 5/8”
Base Plate Dimensions 10-5/8” L x 5-5/16” W x 3/8” H
Fence Guide Dimensions 6-1/8” L x 10-3/16” W x 1-1/16” H
Additional Features Sealed Radial Armature Bearing / Push Button Spindle Lock
Easy Access Carbon Brushes
Overall Dimensions 11-1/8” L x 9-5/8” W x 9” H
Net Weight 8.90 Pounds
CAUTION
LASER LIGHT
DO NOT STARE
INTO BEAM
Max. Output: <1 mW,
Wavelength: 650 nm
CLASS II LASER PRODUCT
This product complies
with 21 CFR 1040.10
and 1040.11
CEN-TECH
3491 Mission Oaks Blvd.,
Camarillo, CA, USA, 93011
Manufacture Date:
, ___________
