6. To clean the exterior parts of the Circular Saw, use only a clean cloth and mild
detergent to clean the body of the Saw. Do not immerse any electrical part of
the tool in any liquids.
7. CAUTION! All maintenance, service, or repairs not mentioned in this
manual must only be performed by a qualified service technician.
SKU 95004 For technical questions, please call 1-800-444-3353 PAGE 18
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN
THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES
THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED
TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISKS AND LIABILITY ARISING OUT OF
HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF
HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
PARTS LIST
Part # Description Qty. Part # Description Qty.
1 Guide Ruler 1 38 Spring 1
2 Rivet 2 39 Spindle Lock 1
3 Screw 1 40 Spring 1
4 Base 1 41 Safety Cover Wrench 1
5 Screw (M6 x 16) 1 42 C-Ring (#10) 1
6 Angle Bracket 1 43 Nut (M6) 1
7 Orientation Block 1 44 Depth Lock 1
8 Screw (M6 x 10) 1 45 Large Washer 1
9 Washer 1 46 Depth Bracket 1
10 Nut (M6) 1 47 Screw (M6 x 14) 1
11 Blade Housing 1 48 Screw (M6 x 16) 1
12 Screw 1 49 Bearing (6000Z) 1
13 Laser Plate 1 50 C-Ring (#12) 1
14 Screw 1 51 Rotor 1
15 Spring Washer 1 52 Bearing (607Z) 1
16 Washer 1 53 Bearing Cover 1
17 Laser Plate Cover 1 54 Air Baffle Plate 1
18 Outer Plate 1 55 Screw (ST4.8 x 60) 2
19 Spring Pin (6 x 40) 1 56 Stator 1
20 Saw Blade 1 57 Housing 1
21 Inner Plate 1 58 Screw (M5 x 58) 3
22 Spindle 1 59 Carbon Brush Holder 2
23 Key (3 x 10 x 7) 1 60 Carbon Brush 2
24 Screw (M4 x 8) 4 61 Carbon Brush Cover 2
25 Safety Cover Plate 1 62 Nut (M5) 2
26 Safety Cover 1 63 Right Handle 1
27 Screw (M5 x 8) 3 64 Cord Clamp 1
28 Bearing (6001Z) 1 65 Screw (ST4.2 x 14) 2
29 Bearing Holder 1 66 Cord Sleeve 1
30 Orientation Steel Cover 1 67 Power Switch 1
31 Screw (M5 x 14) 3 68 Power Cord/Plug 1
32 Gear 1 69 Hex Wrench 1
33 Spring Washer (#5) 4 70 Screw (ST4.2 x 12) 1
34 Wave Spring Washer (#12) 1 71 Left Handle 1
35 C-Ring (#12) 1 72 Screw (ST$.2 x 16) 4
36 Oilless Bearing 1 73 Screw (M5 x 25) 2
37 Gear Box 1 74 Laser Switch 1
