4-2. Meter Functions
. The meters display the actual weld output values for approximately three seconds after the arc is broken.
Mode Meter Reading At Idle Meter Reading While Welding
MIG
Preset Volts Blank
VA
24.5
Actual Volts Actual Amps
VA
24.5 250
Pulsed
MIG
Blank Pulse Display
V Trim
50
Actual Volts Actual Amps
VA
24.5 250
Stick
Contactor Remote
Blank Preset Amps
VA
85
Actual Volts Actual Amps
VA
24.5 85
Stick
Contactor ON
Actual Volts (OCV) Preset Amps
VA
80.0 85
Actual Volts Actual Amps
VA
24.5 85
Manual
Pulse
Pulses Per Second
VA
PPS 200
Actual Volts Actual Amps
VA
24.5 85
. The Stick mode provides the Adaptive Hot Start feature, which automatically increases the output amperage at the start of a weld should the
start require it. This eliminates electrode sticking at arc start.
