19
OPERATING THE TRIMMER/EDGER
OREGON® Cordless Tool System
TRIMMER/EDGER MODEL ST275
AB 0214 - F/N 564571
CHARGING THE BATTERY PACK
WARNING: FAILURE TO FOLLOW
PROPER CHARGING PROCEDURES
MAY CAUSE EXCESSIVE VOLTAGE,
EXCESSIVE CURRENT FLOW, LOSS
OF CONTROL DURING CHARGING,
LEAKAGE OF HAZARDOUS
CHEMICALS, HEAT GENERATION,
BURSTING, OR FIRE. FOLLOW THESE
CHARGING INSTRUCTIONS.
With the charger cord connected to the
charger and plugged into an electrical
outlet, align the grooves in the battery
with the rails on the charger and slide the
battery pack onto the charger until fully
seated (Fig. ).
Check the charge-state indicator for
charging conditions.
INSERTING AND RELEASING
THE BATTERY PACK
Only use the OREGON® brand battery
packs specified in these operating
instructions.
Align the groove in the battery with the
rails inside the battery port. Firmly insert
the battery pack into the trimmer/edger’s
battery port, pressing forward until it
clicks as it locks into place (Fig. ).
To remove the battery pack, lift up on
the battery release, grasp the sides of the
battery pack, and remove it (Fig. ).
FIG. 10
FIG. 11
FIG. 12
