81 MS6000-EU-EN V1.4 8/12
Measurements
Cursors
Voltage difference between cursors: V
Time difference between cursors: T
Reciprocal of T in Hertz (1/ΔT)
Automatic
Measurements
Frequency, Period, Mean, Peak-to-peak, CycleRMS, Minimum,
Maximum, Rise Time, Fall Time, Positive Width, Negative Width,
Delay 1-2↑, Delay 1-2↓, +Duty, -Duty, Base, Top, Middle, Amplitude,
Overshoot, Preshoot, RMS, Off
General Specifications
Display
Display Type 5.6 Inch width LED Backlight Display
Display Resolution 240 (Vertical) X 320 (Horizontal) pixels
Display Contrast Adjustable (16 steps) with a progress bar
Probe Compensator Output
Output Voltage,
typical
About 2Vpp into ≥1MΩ load
Frequency, typical 1kHz
Internal Memory
2G SD Card
Accommodates up to 32G card (accessible through battery
compartment)
Power Supply
Supply Voltage
100-120VAC
RMS
(±10%), 45Hz to 440Hz
120-240VAC
RMS
(±10%), 45Hz to 66Hz
Power Consumption <30W, (approx. 3 hours)
Fuses Two (2) fast-acting internal fuses: 1A (600V) and 12A (600V)
Battery 7.4V li-ion rechargeable
