REEL HEIGHT ADJUSTMENT
Below are the various ways that the Sweep Star 48 castor wheels can be adjusted to accomodate for the finger/
brush reel height. By changing the two spacers around on the castor wheel fork you can experience a range of
ground clearances on the finger/brush reel. Keep both castor wheels at the same height.
These clearances change as the brush and finger reels wear.
No Spacer
Top Hole
Ground Clearance
Brush Reel
7
/
8
"
Finger Reel
1
/
2
"
1
/
2
" Spacer
Top Hole
Ground Clearance
Brush Reel
3
/
4
"
Finger Reel 1
1
/
8
"
1" Spacer
Top Hole
Ground Clearance
Brush Reel
5
/
8
"
Finger Reel 1
1
/
4
"
1" Spacer
1
/
2
" Spacer
Top Hole
Ground Clearance
Brush Reel 1
1
/
8
"
Finger Reel 1
7
/
16
"
1" Spacer(2 per)
1
/
2
" Spacer(1 per)
Bottom Hole
Ground Clearance
Brush Reel 1
1
/
2
"
Finger Reel 1
7
/
8
"
