Reference
QUICK REFERENCE REPLACEMENT PARTS
REPLACEMENT FILTERS
23-031 Hydraulic Oil Filter (Ground Dump)
48-083-01 Hydraulic Oil Filter (High Dump)
78-090 Oil Filter Kohler# 12 050 01
76-324-01 Air Element Kohler# 28 083 03
76-324-02 Pre-Cleaner Kohler# 28 083 02
50-403 Fuel Filter for Kohler
REPLACEMENT BELTS
76-200 Finger Reel Belt 2/A74
SEAL KITS
76-023 3-Bank Hydraulic Valve
14-096 O-Ring Seal Kit
76-322 Hydrostatic Pump (High Lift)
42-003 Hydrostatic Pump (Ground Dump)
14-098 Seal Kit
76-323 Gear Pump (non-repairable)
48-137 Wheel Motor
14-080 Seal Kit
76-242 Hydraulic Cylinder
76-242-01 Seal Kit
Both Cylinders have the part number stamped on them. Look at the rod end, it will have either a retain-
ing ring or a spanner nut.
Cylinders with a Spanner Nut:
75-714 Hydraulic Cylinder Use 14-268 Seal Kit
75-634 Hydraulic Cylinder Use 14-268 Seal Kit
Cylinders with a Retaining Ring:
75-714 Hydraulic Cylinder Use 14-254 Seal Kit
75-634 Hydraulic Cylinder Use 14-254 Seal Kit
FLUIDS
Engine Oil Kohler SJ or Higher 10W-30
Hydraulic Fluid SJ or Higher 10W-40
OTHER PARTS
13-288 Key Switch Kohler Kohler 25 099 04
Spark Plugs Champion® type RC 12YC or Equivalent
Gap 0.030 (.76 mm)
Torque 18/22 ft. lbs (24/30 Nm)
Spline Grease #77 Assembly Paste (Kohler # 25 357 12-s)
76-354 2
1
/
2
# ABC Dry Chemical Fire Extinguisher
DUST AND FILTRATION FILTERS
48-064 Hopper Filter (High Lift)
48-065 Tailgate Filter (High Lift)
48-063 Tailgate Filter (Ground Dump)
48-122 Hopper Filter (Ground Dump)
