Parts
ENGINE AND EXHAUST PARTS LIST
(HIGH LIFT)
REF# PART# DESCRIPTION QUANTITY
1 48-128 Tail Pipe 1
2 48-106 Muffler 1
3 23-184 Male Connector 1
4 18-161 Straight Thread Elbow 2
5 23-139 Barb Fitting 2
6 23-133 Elbow 1
7 76-322 Hydrostatic Pump 1
HSSHS-12-13-175 Socket Set Screw
1
/2 - 13 x 1
3
/4 2
HWL-12 Lock Washer
1
/2 2
8 34-163 Cable Bracket 1
HB-14-20-075 Bolt
1
/4 - 20 x
3
/4 1
HNTL-14-20 Lock Nut
1
/4 - 20 1
9 76-324 Engine Kohler T-18 1
76-324-03 Crankshaft Splined Insert (Kohler # 48 755 23 part of engine) 1
42-113 Solenoid (Kohler # 25 435 02 part of engine) 1
HB-516-18-350 Bolt
5
/16 - 18 x 3
1
/2 4
HW-516 Washer
5
/16 4
HNTL-516-18 Lock Nut
5
/16 - 18 4
10 48-112 Belt Guard 1
11 48-168 Guard Extension 1
78-274 Cage Nuts 3
12 HSTP-14-20-075 Phillips Truss Head Machine Screw
1
/4 - 20 x
3
/4 3
13 48-033 Engine Mount 2
14 23-127 Elbow 2
15 48-035 Shift Arm 1
8946-1 Plastic Wear Strip 1
HRS-316-050 Rivet
3
/16 x 1
1
/2 1
HRP-14-100 Roll Pin
1
/4 x 1 1
16 76-323 Gear Pump (replacement only; no repair) 1
17 23-130 Elbow 1
18 18-133 Barb Fitting 1
19 13-498 Muffler Clamp 1
21 48-142 Rear Engine Guard 1
HSTP-14-20-100 Phillips Truss Head Machine Screw
1
/
4
- 20 x 1 3
HW-14 Washer
1
/
4
3
HWL-14 Lock Washer
1
/
4
3
HN-14-20 Nut
1
/
4
- 20 3
22 48-180 Engine Cover 1
23 48-143 Front Engine Guard 1
HSTP-14-20-100 Phillips Truss Head Machine Screw
1
/
4
- 20 x 1 3
HW-14 Washer
1
/
4
3
HWL-14 Lock Washer
1
/
4
3
HN-14-20 Nut
1
/
4
- 20 3
24 48-171 Spacer 2
25 HB-516-18-350 Bolt
5
/16 - 18 x 3
1
/2 2
HW-516 Washer
5
/16 2
HWL-516 Lockwasher
5
/16 2
(Continued on next page)
