HYDRAULIC DIAGRAM PARTS LIST
(GROUND DUMP)
REF# PART# DESCRIPTION QUANTITY
1 42-003 Hydrostatic Pump 1
2 8917-17 Hose
3
/4 ID 1
18-077 Hose Clamp 2
8895-20 Hose Wrap 20" 1
18-222 Hose Clamp 2
3 8810-19 Hose
5
/8 ID 1
18-077 Hose Clamp 2
8895-34.5 Hose Wrap 34.5" 1
18-222 Hose Clamp 2
4 23-006 Oil Filter 1
23-031 Filter Element (replacement only) 1
5 48-135 Oil Tank 1
6 48-060 Hydraulic Hose 1
8895-73.5 Hose Wrap 73.5" 1
18-222 Hose Clamp 2
7 34-105 Oil Cooler 1
8 76-104 Hydraulic Hose 1
8895-20 Hose Wrap 20" 1
18-222 Hose Clamp 2
9 48-016 Hydraulic Hose 2
8895-60 Hose Wrap 60" 2
18-222 Hose Clamp 4
10 76-321 Wheel Motor 2
11 48-015 Hydraulic Hose 4
12 34-057 Tee 2
42-003 Hydrostat Pump
Displacement Variable to .913 in
3
/R(15 cc
3
/R)
14.23 GPM(53.85LPM) at 3600 RPM
Max Operating Speed 3600 RPM
Rated Pressure 3000 PSI(206.8 Bar)
Max Pressure 4500 PSI(310 Bar)
Max Inlet Vacuum 5 in Hg(.17 Bar)
Max Inlet Temperature 220°F(104°C)
Max Allowable Case Pressure 25 PSI(1.72 Bar)
