-17-
2/5",%(//4).'5)$%#/.4).5%$
Many common problems can be solved easily by utilizing the chart below. For more serious or
persistent problems, contact a Bosch service center or call 877-BOSCH-99.
Read instruction manual first! Remove battery pack and nails from the tool
before making adjustments, assembling accessories or servicing.
1. Jammed fastener
2. Damaged or worn return system
3. Debris in nosepiece
4. Damaged driver blade assembly
1. Remove battery pack from tool. Refer to “jam clearing” on page 12 for details.
2. Replace return system; see page 19 or see authorized service center
3. Clean nosepiece
4. Replace drive assembly; see page 21 or see authorized service center
1. Battery pack not charged, or battery pack is damaged.
2. Depth adjustment set too shallow
3. Tool not firmly applied to workpiece
4. Material and fastener length too rigorous an application
5. Damaged or worn driver blade tip
6. Damaged or worn driver/return assembly
1. Charge or replace battery
2. Rotate depth adjustment wheel to a deeper setting
3. See instruction manual
4. Choose appropriate material or fastener length
5. Replace driver/return assembly; see page 21 or see authorized service center
6. Replace driver/return assembly; see page 21 or see authorized service center
1. No fasteners in magazine
2. Wrong size or angle fasteners
3. Debris in nosepiece
4. Debris in magazine
5. Worn magazine
6. Damaged or worn return system
7. Damaged or worn driver blade
8. Damaged follower spring
1. Load fasteners into magazine
2. Use only recommended fasteners
3. Clean nosepiece
4. Clean magazine
5. Replace magazine; see authorized service center
6. Replace return system; see page 19 or see authorized service center
7. Replace driver assembly; see page 21 or see authorized service center
8. Replace spring; see authorized service center
!
WARNING
BM 2610034445 03-14_FNH180 3/27/14 11:52 AM Page 17
