12
English
(7) If no abnormal operation is observed, you
may load nails in the Nailer.
Drive nails into the workpiece that is
the same type to be used in the actual
application.
□ The nailer must operate properly.
Adjusting air pressure
WARNING
Do not exceed 120 psi (8.3 bar 8.5 ●
kgf/cm
2
).
Adjust the air pressure at recommended
operating pressure 70 – 120 psi (4.9 – 8.3
bar 5 – 8.5 kgf/cm
2
) according to the length of
nails and the hardness of workpiece.
The correct air pressure is the lowest pressure
which will do the job. Using the Nailer at a
higher than required air pressure unnecessarily
over stresses the Nailer.
Loading nails
WARNING
When loading nails into the nailer, ●
be sure to remove your fi nger from
the trigger and disconnect the air
hose from the nailer.
(1) Insert nail strip into rear of magazine.
Magazine
(2) Slide the nail strip forward in the magazine.
The nail strip should pass the nail stopper.
Nail Stopper
(3) Pull the nail feeder (B) back to engage the
nail feeder (A) to the nail strip.
Nail Feeder (B)
Nail Feeder (A)
NOTE
Use nail strip at least 5 nails remaining. ○
The Nailer is now ready to operate.
Removing the nails:
1 Depress the nail feeder (A) slightly and
slowly slide the nail feeder (B) forward.
2 Remove the nails from the Nailer.
Nail Feeder (A)
1
2
