16
English
5 DISCONNECT AIR HOSE FROM NAILER.
6 Choose a suitable position for the adjuster.
Too Deep
Too Shallow
Turn Adjuster
Turn Adjuster
Flush
Flush
2
2
Using the blow nozzle
WARNING
Be sure to release your fi nger from ●
the trigger before using the blow
nozzle.
Do not point the air outlet at a ●
person.
Do not use the blow nozzle with the ●
push lever left fi t.
This Nailer has a blow nozzle that blows out
wood shavings which occur during work.
Press the knob with your thumb to use the blow
nozzle, as shown in the fi gure.
Knob
Air outlet
NOTE
When the blow nozzle is used for a long time, ●
the nailing force may degrade temporarily.
In this case, allows the air supply pressure
to stabilize before starting work.
Oil in the body or drained water from the ●
compressor can sometimes spout out
of the air outlet. It is recommended that
you once conduct a test before use and
see if such phenomenon happens at an
environment where spouted oil will cause
any inconvenience.
Changing the exhaust direction
WARNING
When changing the exhaust ●
direction, be sure to remove
your fi nger from the trigger and
disconnect the air hose from the
nailer.
The direction of the exhaust vent can be
changed by turning the top cover.
Exhaust
Vent
Top Cover
Using the nose cap
WARNING
When attaching or detaching ●
the nose cap, be sure to remove
your fi nger from the trigger and
disconnect the air hose from the
nailer.
If you like to protect the surface of workpiece
against scratches or markings made by the
push lever, attach the accessory nose cap to
the push lever.
1 DISCONNECT AIR HOSE FROM NAILER.
2 Put the nose cap to the toe of the push
lever.
3 The nose cap is marked to indicate the exit
point of the nail, making alignment easier.
4 When not using the nose cap, secure in
the storage compartment located on the
reverse side of the magazine.
