English
DANGER
1. Operators and others in work area must
wear safety glasses with side shields.
When operating the Nailer,
always wear safety glasses
with side shields, and make
sure others in work area
wear safety glasses, too.
Safety glasses must
conform to the requirements of American
National Standards Institute, ANSI Z87.1
and provide protection against fl ying
particles both from the front and side.
The employer must enforce the use of
safety glasses by the Nailer operator and
others in work area.
2. Never use oxygen or other bottled
gases. Explosion may occur.
Never use oxygen,
combustible gases or any
other bottled gases as
a power source for the
Nailer.
Use of the above gases is
dangerous, as the Nailer will explode.
Use only clean, dry, regulated compressed
air.
WARNING
3. Never point tool at yourself or others in
work area.
Always assume the Nailer
contains fasteners.
Never point the Nailer at
yourself toward yourself or
others, whether it contains
fasteners or not.
If fasteners are mistakenly driven, it can
lead to severe injuries.
Never engage in horseplay with the Nailer.
Respect the Nailer as a working
implement.
SAFETY
IMPORTANT SAFETY INSTRUCTIONS FOR USING NAILERS
READ ALL INSTRUCTIONS
4. Keep fi ngers away from trigger when
not driving fasteners to avoid accidental
fi ring.
Never carry the Nailer with fi nger on
trigger since you could drive a fastener
unintentionally and injure yourself or
someone else.
Always carry the Nailer by the handle only.
5. Choice of triggering method is
important.
Read and understand section titled
“Methods of operation.” (pages 13 – 15)
6. Do not exceed 120 psi. (8.3 bar 8.5 kgf/
cm
2
)
Do not exceed
maximum
recommended
air pressure
120 psi (8.3 bar
8.5 kgf/cm
2
).
Never connect the Nailer to pressure which
potentially exceeds 200 psi (13.7 bar 14
kgf/cm
2
) as the Nailer can burst.
7. Be careful of the following when using
blow nozzle.
1) Do not touch the trigger.
2) Do not point the air outlet at a person.
3) Do not touch the push lever or set it to
pushed up status.
Flying nails can cause severe injury.
8. Always wear ear and head protection.
Always wear ear protection to protect your
ears from loud noise.
Always wear head protection to protect
your head from fl ying objects.
9. Store nailer properly.
When not in use, the Nailer should be
stored in a dry place. Keep out of reach of
children. Lock the storage area.
10. Keep work area clean.
Cluttered areas invite injuries. Clear all
work areas of unnecessary tools, debris,
furniture, etc.
