Using the Image Engine
The Dolphin terminal houses a compact image engine that instantly reads popular 1D and 2D bar codes and supports omni-
directional aiming and decoding for greater flexibility in real-world settings. The image engine can also capture digital images,
such as signatures and pictures of damaged inventory.
Dolphin 9500/9550 Image Engine Specifications
Note: The 5300 image engines contains a high-visibility aimer that projects aiming brackets around the bar code or image
preview for maximum viewability and aiming. For details, see 5300 Red High-Vis Aiming Pattern on page 4-5 and page
4-6.
Dolphin 9501/9551 Laser Engine Specifications
Dolphin 9501/9551 terminals can be equipped with one of three laser engines. For details, see Laser Engine Specifications on
page 11-1.
Terminal 1D 2D Image
Capture
Aiming Omni-Directional
Aiming
Engine Options
Dolphin 9500 Y Y Y Green aiming beam or
Red High-Vis aiming
pattern
Y 5100SR
5300SR
5100SF
Dolphin 9550 YYY Y
Dolphin 9501 Y N N Long-range laser aimer N SE1200HP
SE1200LR
SE1200ALR
Dolphin 9551 YNN N
5100 Standard Range (5100SR)
5300 Standard Range (5300SR)
Code 8 mil Linear 10 mil
PDF417
13 mil UPC 15 mil QR 15 mil Data
Matrix
35 mil
MaxiCode
Working
Range
(.020 cm) (.025 cm) (.033 cm) (.038 cm) (.038 cm) (.089 cm)
Near 3.4 in. (8.6 cm) 3 in. (7.6 cm) 2 in. (5.1cm) 3 in. (7.6 cm) 2.2 in. (5.6 cm) 1.9 in. (4.8 cm)
Far 7.5 in. (19 cm) 8.9 in.
(22.6 cm)
13.1 in.
(33.3 cm)
8.7 in. (22 cm) 10.1 in.
(25.6 cm)
12.9 in.
(32.7 cm)
5100 Smart Focus (5100SF)
Code 6.6 mil
PDF417
7.5 mil Linear 10 mil Linear 10 mil
PDF417
13 mil UPC 15 mil Data
Matrix
Working
Range
(.017 cm) (.019 cm) (.025 cm) (.025 cm) (.033 cm) (.038 cm)
Near 2.7 in. (6.8 cm) 2.4 in. (6.1 cm) 2.1 in. (5.3 cm) 2.1 in. (5.3 cm) 1.9 in. (4.8 cm) 1.7 in. (4.3 cm)
Far 5.9 in.
(14.9 cm)
6.4 in.
(16.2 cm)
7.5 in. (19 cm) 7.5 in. (19 cm) 8.8 in.
(22.3 cm)
7.4 in.
(18.8 cm)
