Dolphin® 9500 Series User’s Guide Rev A
5/15/07
5 - 3
Using the Navigation Keys
Located in the center of each keyboard for easy access with either hand, the navigation keys navigate the cursor through
application screens.
Note: Additional functionality varies according to the application in use.
Using the Modifier Keys
Sticky Key Functionality–ALT and CTRL
Dolphin 9500 terminals support sticky key functionality for the ALT and CTRL keys, which means that you don’t have to press
and hold the ALT and CTRL keys when you press the next key. Instead, you can tap ALT or CTRL and then the next key.
You need to open RegEdit and enable the \HKEY_LOCAL_MACHINE\HARDWARE\DEVICEMAP\KEYBD key.
1. Tap Start > Power Tools > RegEdit .
2. Tap the +-\ sign.
Button Function Button Function
Moves the cursor up one row or line.
&
Page up
Moves the cursor down one row or line.
&
Page down
Moves the cursor one character to the right.
&
Volume up
Moves the cursor one character to the left.
&
Volume down
Name & Key Function
Shift
The SFT key modifies only the next key pressed; it must be pressed before each key
you wish to modify. SFT toggles the keyboard between uppercase alphabet mode and
lowercase alphabet mode.
Use SFT toggle Caps Lock on and off by double-tapping it or by pressing SFT + the
Red modifier key. When Caps Lock is toggled on, characters are uppercase; when
toggled off, characters are lowercase.
ALT and CTRL Functions of the ALT and CTRL keys depend on the software application in use and the
keys pressed in combination with each.
Blue and Red The blue and red keys are used in combination with other keys to type special
characters and perform system functions. Each key modifies only the next key pressed.
The overlay of each keyboard is color-coded to indicate the character typed or function
performed when specific keys are pressed immediately after the blue or red modifier
key.
