Serial Ports
z
Two RS-232 ports with 16C550 UART (or compatible) with
16-byte FIFO buffer. COM2 can support RS-422/485 through
jumper setting.
Parallel Port
z
One parallel port supports SPP/EPP/ECP mode
z
One 2x5 pin header supports AC’97 2.3 Line-in, Line-out, and
Audio Connector
USB Interface
Watchdog Timer
Mic-in signals.
z
Four (4) USB ports, Two external and two internal via pin header;
USB 1.1 compliant.
z
Can be Set to 1 to 255 seconds period. Reset or NMI will be
generated when CPU does not periodically trigger the timer.
PC-104 Interface
z
Direct ISA DMA mode operation.
z
A non-volatile 1Kbit EEPROM is provided to retain application
E2Key
Power Supply
critical read/write data.
z
+5V: 2.58A typical, VIA Mark 533MHz CPU w/ 1x128MB
PC-100/133 module
z
+5V: 2.75A typical, VIA Mark 800MHz CPU w/ 1x128MB
PC-100/133 module
Hardware Monitor
z
System voltage detection
z
CPU temperature detection
IrDA Port
z
Supports Serial Infrared (SIR) and Amplitude Shift Keyed IR
(ASKIR) interface
Operating
Temperature
z
0
°
to 60
°
C
Form Factors
z
5.75”(L) x 4”(W) x 1”(H)
