3301770
CN26 D-SUB 15-pin VGA connector
CN27 5-pin 2.54mm IrDA connector
CN28 TFT LCD connector (DF13-40P-1.25V)
CN29 LCD panel dual-channel 18-bit LVDS/TTL connector, 30 (2x15) pin
header 1.25mm (DF13-30P-1.25V)
CN30 Primary IDE bus connector (44-pin 2.0mm)
CN31 FPC flat type floppy port (one floppy drive only)
CN32 Compact flash storage card socket (behaves as an IDE device
through BIOS setting)
2.2.1 Internal Connectors
1. CN1: Power 4P Connector
The 3301770-R10 is equipped with an onboard external power connector, CN1. You can
connect power directly to CN1 or mount a PC104 compact-size power supply module on top
of the board through the PC-104 interface.
Table 2-4 CN1: Power 4P Connector
PIN DESCRIPTION
1 +5V
2 GND
3 GND
4 +12V
2-11
