Cisco MGX Route Processor Module (RPM-PR) Installation and Configuration Guide
Release 2.1, Part Number 78-12510-02 Rev. C1, August 31, 2004
Chapter 5 Configuring the MGX RPM-PR
Establishing 1:N Redundancy Between Two or More RPM-PR Cards
Note After you enter the addred command, the switch resets the secondary card; therefore, the
secondary card will be unavailable for a few minutes.
Step 5 When the reset is complete, enter the dspcds command to show the primary and secondary cards in the
active and standby states, respectively.
The redundant RPM cards are shown in slots 2 and 11 with the standby card in slot 11.
Switch.7.PXM.a > dspcds
Switch System Rev: 02.01 Mar. 19, 2001 23:14:58 GMT
Chassis Serial No: SAA03230404 Chassis Rev: B0 GMT Offset: 0
Node Alarm: MAJOR
Card Front/Back Card Alarm Redundant Redundancy
Slot Card State Type Status Slot Type
--- ---------- -------- -------- ------- -----
01 Empty --- --- --- ---
02 Active/Empty RPM-PR NONE 11 PRIMARY SLOT
03 Empty --- --- --- ---
04 Empty --- --- --- ---
05 Empty --- --- --- ---
06 Failed/Empty AXSM_1OC48 MINOR NA NO REDUNDANCY
07 Active/Active PXM45 NONE 08 PRIMARY SLOT
08 Empty Resvd/Empty --- MAJOR 07 SECONDARY SLOT
09 Empty --- --- --- ---
10 Empty --- --- --- ---
11 Standby/Empty RPM-PR NONE 11 SECONDARY SLOT
12 Empty --- --- --- ---
13 Empty --- --- --- ---
14 Empty --- --- --- ---
Step 6 To display the redundancy relationship between all cards in the switch, enter the dspred command.
Redundant cards are displayed as shown below, indicating primary and secondary slot numbers, card
types, card states, and redundancy type.
Switch.7.PXM.a > dspred
Switch System Rev: 02.01 Mar. 19, 2001 23:15:37 GMT
MGX8850 Node Alarm: MAJOR
Primary Primary Primary Secondary Secondary Secondary Redundancy
SlotNum Type State SlotNum Type State Type
------- ------- --------- --------- --------- --------- ----------
2 RPM-PR Active 11 RPM-PR Standby 1-n
7 PXM45 Active 8 PXM45 Empty Resvd 1-1
Step 7 Return to the primary RPM by entering the cc command, cc <redPrimarySlotNum>.
Unknown.7.PXM.a > cc 2
Step 8 Enter copy run start to save the configuration to the PXM-45 hard disk E:RPM directory.
This file will be used as the configuration file. The name of the file is auto_config_slot# where # is the
primary slot number.
Note This step is mandatory for redundancy to work.
