A-3
Cisco ASR 9001 and Cisco ASR 9001-S Routers Hardware Installation Guide
OL-26701-02
Appendix A Technical Specifications
Table A-3 lists the AC electrical specifications for the Cisco ASR 9001 Router.
Caution Be sure that the chassis configuration complies with the required power budgets. Failure to properly
verify the configuration may result in an unpredictable state if one of the power units fails. Contact your
local sales representative for assistance.
Table A-4 lists the DC electrical specifications for the Cisco ASR 9001 Router.
Table A-3 Cisco ASR 9001 AC Electrical Specifications
Description Value
Power modules per system Up to two AC power modules per system
Total AC input power 765 VA (volt-amps) per AC power supply
(up to two AC power supply modules per system)
Rated input voltage
1
1. For each AC power supply module.
100–240 VAC nominal (range: 90 to 264 VAC)
220–240 VAC (UK)
Rated input line frequency
1
50/60 Hz nominal (range: 47 to 63 Hz)
50/60 Hz (UK)
Input current rating
1
15 A maximum at 100 VAC
13 A maximum at 220 to 240 VRMS (UK)
Source AC service
requirement
1
15 A North America and Japan; 10 A international; 13 A UK
Redundancy Power redundancy requirements vary, based on system configuration
(number and type of line cards, etc). AC powered systems are 2N
protected and DC powered systems are N+1 protected.
Table A-4 Cisco ASR 9001 DC Electrical Specifications
Description Value
Power modules per system Up to two DC power modules per system
Total DC input power per
power module
750 W
Rated input voltage per
power module
–48 VDC nominal in North America
–60 VDC nominal in the European Community
(range: –40.5 to –72 VDC [–75 VDC for 5 ms])
Input current rating
1
1. For each DC power supply module. Some power/chassis configurations may operate at lower current ratings than those
specified in this table. Contact your Cisco technical representative for more information.
15 A maximum at –48 VDC nominal
15 A maximum at –60 VDC nominal
Source DC service
requirement
1
Sufficient to supply the rated input current. Local codes apply.
Redundancy Power redundancy requirements vary, based on system configuration
(number and type of line cards, etc). AC powered systems are 2N
protected and DC powered systems are N+1 protected.
