A-4
Cisco ASR 9001 and Cisco ASR 9001-S Routers Hardware Installation Guide
OL-26701-02
Appendix A Technical Specifications
Table A-5 lists the AC input voltage range for the AC-powered Cisco ASR 9001 Router (single phase
power source).
Table A-6 lists the DC input voltage range for the DC-powered Cisco ASR 9001 Router.
Table A-7 lists the DC output tolerances for either AC or DC power modules.
Table A-8 lists the RP port specifications.
Table A-5 AC Input Voltage Range
Range Minimum
Minimum
Nominal Nominal
Maximum
Nominal Maximum
Input Voltage 90 VAC 100 VAC 220 VAC 240 VAC 264 VAC
Line Frequency 47 Hz 50 Hz 50/60 Hz 60 Hz 63 Hz
Table A-6 DC Input Voltage Range
Range Minimum Nominal Maximum
Input Voltage –40 VDC –48 VDC –72 VDC
Table A-7 DC Output Levels for ASR 9001 Power System
Parameter Value
Voltage
Maximum 12.6 VDC
Nominal 12 VDC
Minimum 11.4 VDC
Power
Minimum (one power module) 750 W
Maximum (two 750 W power modules) 1500 W
Table A-8 RP Port Specifications
Description Value
Console port EIA/TIA-232 RJ-45 interface, 115200 Baud, 8 data, no
parity, 1 stop bit with software handshake (default)
Auxiliary port EIA/TIA-232 RJ-45 interface, 115200 Baud, 8 data, no
parity, 1 stop bit with software handshake (default)
Management ports (0, 1) Triple-speed (10M/100M/1000M) RJ-45
Sync ports (0, 1) Can be configured as one of the following:
• BITS (Building Integrated Timing System) port
• J.211 or UTI (Universal Timing Interface) port
