Page 45
Key
No. Description Quan.
Key
No. Description Quan.
* Item 96 includes parts 42, 78, 100 through 106, and 111.
106 Washer ....................................................... 1
107 Washer ....................................................... 1
108 Spacer ........................................................ 1
109 Screws ...................................................... 12
110 Hang Tag .................................................... 1
111 Back-Up Plate ............................................ 1
112 Screw (10-24 x 3/4 in. Flat Hd.) ................. 2
113 Bolt Holder .................................................. 1
114 Rear Switch Cover ...................................... 1
115 Switch Key .................................................. 1
116 Screw (8-16 x 3/8 in. Pan Hd.) ................... 4
117 Switch ......................................................... 1
94 Rip Fence Assembly .................................. 1
95 Blade Guard Assembly............................... 1
96 *Accessory Table Assembly ........................ 1
97 Grounding Label ......................................... 1
98 Throat Plate ................................................ 1
99 Screw .......................................................... 1
100 Accessory Table ......................................... 1
101 Handle Shaft ............................................... 1
102 Handle ........................................................ 1
103 Spring Plate ................................................ 1
104 Retaining Ring ............................................ 1
105 Hex Nut (1/4-20) ......................................... 1
RYOBI 10 in. (254 mm) TABLE SAW - MODEL NO. BT3100-1
PARTS LIST - FIGURE 58 (CONT'D)
WARNING:
Improper electrical repair of the table saw can result in damage to the drive system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool require safety testing and should only be performed by a
Ryobi Authorized Service Center.
