85054B 2-5
Specifications
Electrical Specifications
Electrical Specifications
The electrical specifications in Table 2-3 apply to the devices in your calibration kit when
connected with an Agilent precision interface.
Certification
Agilent Technologies certifies that this product met its published specifications at the time
of shipment from the factory. Agilent further certifies that its calibration measurements
are traceable to the United States National Institute of Standards and Technology (NIST)
to the extent allowed by the institute’s calibration facility, and to the calibration facilities
of other International Standards Organization members. See “How Agilent Verifies the
Devices in This Kit” on page 4-2 for more information.
Table 2-3 Electrical Specifications
Device Frequency (GHz) Parameter Specification
Lowband loads DC to ≤2 Return Loss ≥48 dB (≤0.00398ρ)
Sliding loads
a
a. The specifications for the sliding load termination include the quality of the airline
portions within the sliding load combined with the effective stability of the sliding
element.
> 2 to ≤18
Return Loss
≥42 dB (≤0.00794ρ)
Adapters
(both styles)
DC to ≤8
> 8 to ≤18
Return Loss
Return Loss
≥34 dB (≤0.0200ρ)
≥28 dB (≤0.0398ρ)
Offset Opens
b
b. The specifications for the opens and shorts are given as allowed deviation from the
nominal model as defined in the standard definitions (see “Nominal Standard Definitions”
on page A-11).
at 18 Deviation from Nominal
Phase
±1.5°
Offset Shorts
b
at 18 Deviation from Nominal
Phase
±1.0°
