Grizzly G0554Z Lathe User Manual





Saddle & Cross Slide Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
501 P0554Z0501 CROSS SLIDE GIB 533 PS09M PHLP HD SCR M5-.8 X 10
502 P0554Z0502 GIB ADJUSTMENT SCREW 534 P0554Z0534 GRADUATED DIAL
503 PS09M PHLP HD SCR M5-.8 X 10 535 P0554Z0535 HANDWHEEL
505 P0554Z0505 WIPER PLATE 536 P0554Z0536 HANDWHEEL SCREW
506 P0554Z0506 CROSS SLIDE BODY 537 PSS12M SET SCREW M6-1 X 25
507 P0554Z0507 T-BOLT 538 P0554Z0538 HANDLE
508 P0554Z0508 HUB 540 P0554Z0540 COMPRESSION SPRING
509 P0554Z0509 BALL OILER 8MM 541 P0554Z0410 STEEL BALL 6MM
510 PSB02M CAP SCREW M6-1 X 20 542 P0554Z0542 SADDLE
511 P0554Z0511 SLEEVE 543 P0554Z0543 PIN 6 X 40
512 PSS20M SET SCREW M8-1.25 X 8 544 P0554Z0544 WIPER PLATE
513 PN02M HEX NUT M10-1.5 545 PS09M PHLP HD SCR M5-.8 X 10
514 P0554Z0514 BEARING CAP 547 PSB45M CAP SCREW M8-1.25 X 45
515 PSB07M CAP SCREW M6-1 X 30 548 P0554Z0509 BALL OILER 8MM
516 P8101 THRUST BEARING 8101 550 P0554Z0550 WIPER PLATE
517 P0554Z0517 BLOCK 551 P0554Z0551 REAR PRESSURE PLATE
518 P0554Z0518 SPACER 552 P0554Z0552 SADDLE GIB
519 P0554Z0519 CROSS SLIDE LEADSCREW 553 PLN03M LOCK NUT M6-1
520 PSB26M CAP SCREW M6-1 X 12 554 PSS25M SET SCREW M6-1 X 20
521 P0554Z0521 LEADSCREW NUT 555 PSB14M CAP SCREW M8-1.25 X 20
522 PS49M PHLP HD SCR M3-.5 X 5 556 P0554Z0556 HANDLE KNOB M10-1.5
523 PK23M KEY 5 X 5 X 25 557 P0554Z0557 HANDLE LEVER
524 P0554Z0524 GEAR SHAFT 20T 558 P0554Z0558 HANDLE HUB
525 PK48M KEY 4 X 4 X 20 559 P0554Z0559 OIL FILL CAP
526 P0554Z0526 BALL OILER 6MM 560 P0554Z0560 LOCK STUD
527 PS12M PHLP HD SCR M3-.5 X 6 561 P0554Z0561 FRONT PRESSURE PLATE
528 P0554Z0528 INDEX PLATE 562 P0554Z0562 STRAIN RELIEF
529 P0554Z0529 BEARING HOUSING 563 P0554Z0563 LAMP BRACKET
530 PSB29M CAP SCREW M6-1 X 40 564 P0554Z0564 WIPER PLATE
531 P8102 THRUST BEARING 8102 565 P0554Z0565 SPECIAL PIN
532 P0554Z0532 END CAP 566 P0554Z0566 SLEEVE
