-28-
G0605X/G0606X Extreme Series 12" Table Saw
12. Model G0606X only: Verify that the power is
not connected out of phase by starting/stop
-
ping the table saw and
determining if the
motor turns in the correct direction, using the
criteria below:
— If the
blade turns clockwise (as standing in
front of the table saw
), it is turning in the
correct direction.
— If the
blade turns counterclockwise, toward
the back of the saw, it
is turning in the
wrong direction.
Stop the table saw,
shut OFF the power
source, swap any two of the three power
wires—L1, L2, or L3—that connect to the
saw. If using a phase converter for 220V 3-
phase operation, ONLY swap
L1 and L2.
13. Verify that the arbor nut is secure. The saw is
now ready to operate.
Figure 35. Example of switching incoming power
wires.
Incoming
Power
Wires
Contactor
