For technical questions, please call 1-800-444-3353;
Troubleshooting section at end of manual.
Page 25SKU 55525
INSPECTION, MAINTENANCE, AND CLEANING
WARNING!
Before performing any maintenance on the Welder, unplug the
Power Cord (13) from its electrical outlet and allow all components of
the Welder to completely cool.
Periodically open the Access Panel (12) from the unit and, using compressed air,
blow out all dust and debris from the interior.
Always store the Welder in a clean, dry, safe location out of reach of children and
other unauthorized people.
For optimal weld quality, clean and inspect the Contact Tip (15g) and Nozzle (15h)
before each use, as follows:
NOZZLE INSPECTION, CLEANING, AND REPLACEMENT
Turn the Nozzle (15h) counterclockwise while pulling to remove.
Scrub the interior of the Nozzle (15h) clean with a wire brush.
Examine the end of the Nozzle (15h). The end should be flat and even. If the end is
uneven, chipped, melted, cracked, or otherwise damaged, the Nozzle will adversely
effect the weld and should be replaced.
Reinstall the Nozzle (15h) after inspecting and cleaning the Contact Tip (15g).
CONTACT TIP INSPECTION, CLEANING, AND REPLACEMENT
Make sure the entire Welding Torch (15) is completely cool before proceeding.
Remove the Nozzle (15h) as explained above. Then remove the Contact Tip (15g).
Scrub the exterior of the Contact Tip (15g) clean with a wire brush. Check that the
Contact Tip is the proper type for the wire size used.
Examine the hole at the end of the Contact Tip (15g) for the following problems:
Shape: The hole should be an even circle, and should not be oblong or have any
bulges in it.
Size: The Contact Tip will decrease in efficiency as the center hole enlarges. A
Contact Tip that measures 150% or more the original size* should be replaced.
(*.045” or more for .030” Tips; .035” or more for .023 Tips.)
If any problems are noted with a Contact Tip (15g), have it replaced.
When inspection and maintenance is completed, reinstall the Contact Tip (15g)
and Nozzle (15h).
