For technical questions, please call 1-800-444-3353;
Troubleshooting section at end of manual.
Page 28SKU 55525
PARTS LIST
Part Description Qty.
1 Side Panel 1
2 Hinge 2
3 Handle Socket 2
4 Handle 1
5 Fan 1
6 Back Panel 1
7 Rectifier 1
8 Inner Panel 1
9 Wire Spool Axle 1
10 Wire Feed Mechanism* 1
10a Swing Arm 1
10b Tension Adjusting Knob 1
10c Tensioning Arm 1
10d Tension Spring 1
10e Tension Pusher 1
10f Wire Feed Leader 1
10g Screw 4
10h Cable Clamp 1
10i Liner Sleeve 1
10j Key 1
10k Feed Roller Bracket 1
10l Screw 2
11 Wire Feed Wheel (0.6 & 0.8 mm) 1
12 Access Panel 1
13 Line Cord 1
14 Ground Cable With Clamp 1
15 Welding Torch/Cable Assembly 1
15a Protective Sleeve 1
15b Locking Collar 1
15c Lower Housing 1
15d Trigger 1
15e Switch Body 1
15f Head Tube 1
Part Description Qty.
15g Contact Tip (.8 mm) 1
15h Nozzle 1
15i Push-lock Coupler 2
15j Gas Hose 1
15k Liner 1
15l Power Cable 1
15m Upper Housing 1
16 Cover 1
17 Wire Feed Speed Control Knob 1
18 1/2 Switch 1
19 Min/Max Switch 1
20 Power Switch (With Light) 1
21 Cable Relief, Strain 2
22 Front Panel 1
23 Filter Reactor 1
24 Main Transformer 1
25 Transformer Carriage 2
26 Bottom Plate 1
27 Temperature Controller 1
28 Overload Indicator lamp 1
29 Support Shelf of Circuit Board 1
30 Wire Feed Speed Circuit Board 1
31 Potentiometer 1
32 Knob 2
33 Nut, Copper, M6 4
34 Washer, Spring, 6 2
35 Washer, Copper, Plain, 6 4
36 Washer, Insulating, 1 2
37 Nut, Copper, M6x35 2
38 Washer, Insulating, 2 2
39 Spool Knob 1
40 Locking Wing Nut 1
41 Gas Line 1
*Wire feed mechanism includes parts 10a-10j, & 11
