SKU 98198 For technical questions, please call 1-800-444-3353. Page 19
MOTOR
Power
ON/OFF
Switch
Wiring Diagram
The colored wires
connected to the
motor are not speci-
fied because they
are interchangeable.
1 3 5 2 4 6
Motor Thermal
Circuit Breaker
White
Black
Ground
Start Capacitor
120V
