Page 10SKU 91815
UNPACKING
When unpacking, check to make sure that all the parts are included. Refer to the Assembly
section, and the Assembly Drawing and Parts List at the end of this manual.
If any parts are missing or broken, please call Harbor Freight Tools at the number on the
cover of this manual as soon as possible.
ASSEMBLY INSTRUCTIONS
Stand Assembly
Note: Hand tighten the nuts and bolts during assembly.
1. Attach the Stand Legs (62) to the Stand Top (60) front and rear pieces using sixteen 5/
16” x 5/8” Carriage Bolts (61), 5/16” Flat Washers (59), 5/16” Lock Washers (39), and 5/
16” Hex Nuts (58). Refer to Figure C., below.
2. Attach the Cross Braces (63) to the left and right sides of the Stand Legs (62), and
Cross Braces (64) to the front and rear sides of the Stand Legs (62). Use eight 5/16” x
5/8” Carriage Bolts (61), 5/16” Flat Washers (59), 5/16” Lock Washers (39), and 5/16”
Hex Nuts (58).
The longer Cross Braces must be under the longer Stand Top pieces as shown below.
Figure C. Stand Assembly
