SPECIFICATIONS
Model LXSL01
Blade diameter 190 mm (7-1/2")
Hole (arbor) diameter 15.88 mm (5/8")
Max. Miter angle Left 47° , Right 57°
Max. Bevel angle Left 45°, Right 5°
Max. Cutting capacities (H x W) with blade 190 mm (7-1/2") in diameter.
Bevel angle
Miter angle
45° (left) 0° 5° (right)
25 mm x 300 mm 52 mm x 300 mm 40 mm x 300 mm
(1" x 11 - 3/4") (2 - 1/16" x 11 - 3/4") (1 - 9/16" x 11 - 3/4")
* 60 mm x 265 mm (Note 1)
0°
-----
(2-3/8" x 10-3/8")
-----
25 mm x 212 mm 52 mm x 212 mm
(1" x 8 - 3/8") (2 - 1/16" x 8 - 3/8")
-----
----- * 60 mm x 185 mm (Note 2)
45° (left and right)
(2-3/8" x 7-1/4")
-----
52 mm x 163 mm
-----
(2 - 1/16" x 6 - 3/8")
-----
* 60 mm x 145 mm (Note 3)
57° (right)
-----
(2-3/8" x 5-3/4")
-----
No load speed (RPM) 2,200/min.
Dimensions (L x W x H) 655 mm x 430 mm x 454 mm (25-3/4" x 17" x 17-7/8")
Net weight 12.4 kg (27.3 lbs)
Rated voltage D.C.18 V
Standard battery cartridge BL1830
(Note)
* mark indicates that a wood facing with the following thickness is used.
1: When using a wood facing 20 mm thickness
2: When using a wood facing 15 mm thickness
3: When using a wood facing 10 mm thickness
• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
USA005-3
For Your Own Safety Read
Instruction Manual
Before Operating Tool
Save it for future reference
GENERAL SAFETY
PRECAUTIONS
(For All Tools)
1. KNOW YOUR POWER TOOL. Read the owner's
manual carefully. Learn the tool's applications
and limitations, as well as the specific
potential hazards peculiar to it.
2. KEEP GUARDS IN PLACE and in working
order.
3. REMOVE ADJUSTING KEYS AND WRENCHES.
Form habit of checking to see that keys and
adjusting wrenches are removed from tool
before turning it on.
4. KEEP WORK AREA CLEAN. Cluttered areas
and benches invite accidents.
5. DO NOT USE IN DANGEROUS ENVIRONMENT.
Do not use power tools in damp or wet
