Page 24 For technical questions, please call 1-800-444-3353. SKU 32650
Part Description Qty
1 Miter Gauge Assembly 1
1a Miter Scale 1
1b Miter Indicator 1
1c Miter Bar 1
1d
Miter Knob 1
2 Fence Assembly 1
2a Half Fence 1
2b Long Fence 1
3 Motor Assembly 1
3a Brush Cover 2
3b Carbon Brush 2
3c Motor 1
3d Screw 1
3e Motor Pulley 1
4 Knob w/Shaft 4
5 Washer 4
6 Radius Pin 1
7 Table Top 1
8 Table Insert 1
9 Chip Discharge Chute 1
10 #10-24 x 1/2 Pan Head Bolt 6
11 Ring Guard 1
12 Post 1
13 1/2" Washer 1
14 #4 Screw 4
15 Rear Cover 1
16 Height Knob 1
17 Stud 1
18 3/8 Flat Washer 1
19 Bushing 1
20 1/4 Washer 8
21 5/16-18x1/2 Socket Set (screw) 4
22 1/4-20x1 Hex Cap Screw 4
23 Cord Strain Reliever 1
24 Power Cord 1
Part Description Qty
25 Base 1
26 Front Cover 1
27 Switch Assembly 1
27a Switch 1
27b Switch Key 1
28 #10-24x3/8 Pan Head Bolt 3
29 #10 External Tooth Lock Washer 3
30 1/4x1-1/2 Cap Screw 4
31 #8-32x1/2 Pan Head Screw 5
32 #8 External Tooth Lock Washer 5
33 Belt Guard 1
34 Belt 1
35 1/4 Hex Flange Bolt 4
36 Motor Bracket 1
37 3/16 Cable Clamp 1
38 Spindle Pulley 1
39 Bottom Cover Plate 1
40 Spindle Housing 1
41 Internal Retaining Ring 1
42 Ball Bearing 80104 1
43 Main Spindle 1
44 Ball Bearing80202 1
45 External Retaining Ring 1
46 Shaper Spindle Nut 1
47 1/2”-20 Shaper Spindle 1
48 1/2” Keyed Washer 1
49 #1/2”-20 Nut M12 x 1.25 EFT 1
50 Router Bit Collet 1
51 Router Collet Nut #3/4 - 10 1
52 2-1/2 Male to 1-1/4 Female Adapter 1
53 Collar 1
54 Spindle Wrench 1
55 Double Ended Wrench 1
56 Nut (not shown) - Packing nut for
Height Knob Stud
1
PARTS LIST
REV 10e
