2-22
Cisco 800 Series Routers Hardware Installation Guide
78-5373-04
Chapter 2 Installation
Where to Go from Here
Where to Go from Here
You have completed the hardware installation and are ready to configure the software. Cisco strongly
recommends that inexperienced network administrators use the Cisco 800 Fast Step application. Use the
Cisco 800 Fast Step CD-ROM and online help. If you are an experienced network administrator and want
to use the CLI to configure the software, refer to the Cisco 800 Series Routers Software Configuration
Guide.
To digital
telephone
LINE, CH1, CH1 RXD, CH1
TXD, CH2, CH2 RXD, and CH2
TXD
• LINE, CH1, and CH2: On. CH1 or CH2 is
on when the router has an active voice
connection.
• CH1 RXD, CH2 RXD: Blinking when
indicated ISDN B channel receives a
packet.
• CH1 TXD, CH2 TXD: Blinking when
indicated ISDN B channel sends a packet.
To analog
telephone, fax, or
modem
PH1 and PH2
1
On when telephone, fax, or modem is in use.
1. You can also pick up the handset and listen for a dial tone.
Table 2-4 Verifying Installation (continued)
Power/Link LEDs To Check Normal Patterns
