-26-
Model T27313 (Mfd. Since 01/15)
231
232
233 234
235
236
237
238
239
240
241
242
243
244
244
245
246
258
247
247
248
249
250
251
252
253
254
256
255
257
Carriage Breakdown
REF PART # DESCRIPTION REF PART # DESCRIPTION
231 PT27313231 SET SCREW M8-1.25 X 16 245 PT27313245 STYLUS
232 PT27313232 CUTTING TOOL ARBOR 246 PT27313246 EXTENSION SPRING
233 PT27313233 QUILL 247 PT27313247 HEX NUT M8-1.25
234 PT27313234 GAUGE ROD 248 PT27313248 VENTED BOLT M8-1.25 X 65
235 PT27313235 INDICATOR PLATE 249 PT27313249 MOUNTING PLATE
236 PT27313236 LOCK WASHER 5MM 250 PT27313250 CAP SCREW M6-1 X 12
237 PT27313237 PHLP HD SCR M5-.8 X 12 251 PT27313251 HEX BOLT M8-1.25 X 16
238 PT27313238 CARRIAGE SPACER 252 PT27313252 BUSHING (COPPER)
239 PT27313239 LEADSCREW SEAT 253 PT27313253 CARRIAGE CASTING
240 PT27313240 CAP SCREW M6-1 X 30 254 PT27313254 SET SCREW M5-.8 X 12
241 PT27313241 LEADSCREW 255 PT27313255 CUTTING TOOL
242 PT27313242 SET SCREW M8-1.25 X 12 256 PT27313256 HANDWHEEL 98MM DIA DISHED (PLASTIC)
243 PT27313243 HANDWHEEL HANDLE 257 PT27313257 FLAT HD SCR M6-1 X 8
244 PT27313244 SET SCREW M5-.8 X 10 258 PT27313258 MACHINE ID LABEL
