SKU 95668 For technical questions, please call 1-800-444-3353 PAGE 2
PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures, parts list and assembly
diagram. Keep your invoice with this manual. Write the invoice number on the
inside of the front cover. Keep this manual and invoice in a safe and dry place for
future reference.
1. Keep your work area clean and well lit. Cluttered benches and dark areas
invite accidents.
2. Do not operate the Wood Shaper in explosive atmospheres, such as in the
presenceofammableliquids,gases,ordust.Power equipment creates
sparks which may ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operating power
equipment. Distractions can cause you to lose control. Protect others in the work
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electricshock,re,and/orseriousinjury.
SAVE THESE INSTRUCTIONS
WORK AREA
GENERAL SAFETY RULES
Electrical Requirements 110 VAC / 60 Hz / 10.54 Amps (With Load)
Motor Size: 1 HP / Single Phase
Motor RPM: 3450
Spindle Speed: 11,000
Power Cord Length: 70”
Power Cord Specications: SJT 16 AWG x 3C
Plug Type: 3 Prong / Grounded
Spindle Diameter
1/2”
Spindle Thread 12mm x 1.5 pitch, ne thread
Spindle Travel
7/8”
Router Collets ¼” and ½” (included)
Maximum Cutting Diameter 2-7/8”
Table Size
24” Wide x 19” Deep
Footprint 18-7/8” Wide x 16-5/8” Deep
Miter Guide 0 ~ 60° Left to Right
Fence Dimensions
9/16” Long x 11-3/4” Wide x 2-3/4” High (Qty. 2)
Overall Dimensions
26-1/8” Long x 27-1/2” Wide x 36-1/2” High
Gross Weight 187.5 Lb.
REV 10d
