SKU 95668 For technical questions, please call 1-800-444-3353 PAGE 27
PARTS LIST
NOTE:
Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Part # Description Part # Description
1 Side Panel 59 Fence Body (Left)
2 Tie Bar 60 Fence
3 Rubber Foot 61 Lock Handle
4 Philips Head Screw (M4-0.7x25) 62 Flat Washer (1/2”)
5 Power Switch 63 Flat Washer (3/8”)
6 Switch Lamella 64 Knob (M8-1.25)
7 Flat Washer (5mm) 65 Lock Washer (1/2”)
8 Hex Nut (M4-0.7) 66 Hex Bolt (M12-1.75 x 20)
9 Carriage Bolt (M8-1.25 x 12) 67 Adjusting Screw Stud
10 Flat Washer (3/8”) 68 Hand Knob
11 Hex Nut (M8-1.25) 69 Roll Pin (3 x 20)
12 Philips Head Screw (M5-0.8 x 12) 70 Philips Head Screw (M6-1 x 12)
13 Exterior Tooth Washer (5mm) 71 Half Collar
14 Hex Nut (M5-0.8) 72 Adjusting Shaft
15 Shelf 73 Flat Washer (1/2”)
16 Electricity Label 74 Hex Nut (M12-1.75)
75 Hex Bolt (M8-1.25 x 12)
18 Hex Nut (M8-1.25) 76 Flat Washer (3/8”)
19 Flat Washer (3/8”) 77 Hold Down Bar
20 Strain Relief 78 Philips Head Screw (M4-0.7 x 10)
21 Spindle Pulley Guard 79 Hex Post
22 Power Cord 80 Hex Nut (M8-1.25)
23 Wire Cord 81 Flat Washer (3/8”)
82 Mounting Bracket
83 Hand Knob
26 Flat Washer (3/8”) 84 Hex Nut (M4-0.7)
27 Hex Bolt (M8-1.25 x 12) 85 Ring Guard
28 Table Leg 86 Hex Bolt (M8-1.25 x 30)
87 Housing Bracket
30 Hex Bolt (M8-1.25 x 25) 88 Clamp Sleeve (Left)
31 Hex Bolt (M12-1.75 x 30) 89 Stuff Ring
32 Lock Washer (12mm) 90 Roll Pin (3 x 20mm)
33 Table Support 91 Lock Bar
34 Miter Block 92 Hand Knob
35 Flat Washer (1/4”) 93 Roll Pin (3 x 20mm)
36 Philips Head Screw (M4-0.7 x 6) 94 Lock Nut
37 Self Tapping Screw (3.5 x 12mm) 95 Hex Bolt (M12-1.75 x 30)
38 Flat Washer (3/8”) 96 Upper Spindle Nut
39 Support Pole 97 Safety Washer
40 Stud Bolt 98 Rub Collar (1/2” x 1-3/16” x 3/16”)
41 Anti-Kickback Pin 99 Rub Collar (1/2” x 1-3/16” x 1/4”)
42 Miter Bar 100 Rub Collar (1/2” x 1-3/16” x 3/8”)
43 Aluminum Alloy Fence 101 Cutter Spindle
44 Right Fence Lid 102 Collet Nut
44A Left Fence Lid 103 Collet
45 Miter Gauge Body 104 Collet
46 Plastic Handle 105 Spindle
47 Pointer 106 Key (4 x 4 x 20mm)
48 Self Tapping Screw (M3 x 15) 107 Interior Retaining Ring (47mm)
49 Tension Pin (2 x 16mm) 108 Wave Washer (45mm)
50 Carriage Bolt (M6-1 x 35) 109 Ball Bearing
51 Knob (M6-1.0) 110 Spindle Housing
52 Work Table 111 Ball Bearing Sleeve
53 Table Insert (1-3/8” Hole) 112 Ball Bearing
53A Table Insert (1-3/4” Hole) 113 Spindle Pulley
54 Carriage Bolt (M6-1 x 35) 114 Lower Spindle Nut
55 Knob (M6-1.0) 115 Bearing Cone
56 Taper Pin (8 x 75mm) 116 Coil Spring
57 Fence Body (Right) 117 Set Screw (M8-1.25 x 8)
58 Clamp Stud 118 Spring Collar
