3-07
Fill Solution Tank, Utilizing Optional Eductor:
Load the solution tank using the optional eductor via the
following steps:
1. Close
all valves.
2. Remove solution quick fill cap & connect load hose.
3. Open
solution quick fill valve and solution tank main
valve.
4. Open valve on loading reservoir (i.e. nurse tank)
5. Fill eductor with desired amount of chemical to be
pulled into the solution tank. CLOSE Eductor Lid
.
6. Start the remote transfer pump.
7. Once there is a steady flow rate from the nurse tank to
the solution tank, open the eductor valve and close the
solution quick fill valve. Once there is a steady flow
rate again, open
the eductor tank valve for 15-30
seconds.
8. Close the eductor tank valve and verify the chemical
has been completely removed from the eductor tank.
Repeat steps 7 and 8 if chemical remains in the
eductor tank.
9. Run remote transfer pump until the desired amount
of solution is transferred into the sprayer.
10. Close
valves on the loading reservoir.
11. Close
solution quick fill valve, solution tank main
valve and the eductor valve on the sprayer.
12. Remove load line & replace cap on sprayer quick fill.
565 Trailer Sprayer - Operation Instructions
Section B
6
Section B
CAUTION
DO NOT open the lid of the
eductor while in operation as
splashing of chemical may occur.
