3-07
565 Trailer Sprayer - Connection & Startup
Section C
6
Section C
Hydraulic SprayBoom Control
In reference to the hydraulic control functions, the hydraulic
hoses that connect to the tractor have been marked for your
convenience to indicate what function a particular hose
serves. See the identification method to the right.
Direct Tractor Hookup (Option on 565)
Quick couplers should be connected to the tractor. Make
certain to correctly connect the pressure and return line
hoses to the tractor hydraulic ports. As with all the steps of
installation, this should be completed with the tractor engine
turned off to assure no high pressure exists. It is assumed
that adequate filtration, hydraulic flow and hydraulic pres-
sure exists on the tractor, for top performance of this
sprayer. The system comes with three hydraulic quick cou-
pler sets for the three hydraulic cylinders. Connect each set
of couplers to the tractor hydraulic valves. Operate the trac-
tor's hydraulic levers or switches for these hydraulic valves
to operate the cylinders.
Redball
®
Multiplier Valve (Standard on 565)
An optional hydraulic multiplier valve that can provide two
hydraulic functions from one tractor hydraulic valve. See
Section F, Parts and Schematics for more information. The
multiplier valve bank connects to one hydraulic valve on the
tractor with quick couplers. The multiplier valve takes the
flow from this one tractor valve and divides it to one of the
two ports in the valve. One tractor hydraulic valve can pro-
vide two cylinder functions via electric solenoids. The oper-
ator will need to actuate the tractor hydraulic lever or switch
for the tractor hydraulic valve the multiplier connects to and
then activate the multiplier's toggle switch to open the sole-
noids allowing hydraulic oil out of one of the two ports. The
multiplier valve allows one set of solenoids to operate at a
time. When the operation is complete, the operator will
release the multiplier valve toggle switch and return the trac-
tor hydraulic lever or switch to the neutral position. See
Section F Parts & Schematics for further information.
To install, connect hydraulic multiplier valve to one set of
tractor hydraulic remote connectors. Mount switch box in a
convenient location and then connect proper wires of the
valve to a 12-volt power source, and a chassis ground.
Hydraulic Controller
This controller provides a way to operate three hydraulic cir-
cuits with one tractor hydraulic valve. The hydraulic con-
troller is mounted to the sprayer near the center mast and is
meant to remain with the sprayer.
(continued)
Tractor Connections
Hydraulic Marking
Sprayer Pump Pressure - Red, Two Wraps
Sprayer Pump Return - Red, One Wrap
Center Boom Lift Butt - White, One Wrap
Left Boom Rod - Blue, One Wrap
Left Boom Butt - Blue, Two Wraps
Right Boom Rod - Yellow, One Wrap
Right Boom Butt - Yellow, Two Wraps
