3-07
565 Trailer Sprayer - Connection & Startup
Section C
4
Section C
Tire Weight Capacities - 8 MPH
8.3 lb/gal (Water) 750 1000
10.0 lb/gal 750 1000
12.0 lb/gal 750 1000
14.0 lb/gal 750 877
16.0 lb/gal 750 768
Spindle and Hub Assembly: 8-Bolt
Use this chart as a guide to determine the maximum amount of various solu-
tions your sprayer tires are rated for. 8 MPH is the service or field speed for
this sprayer. 20 MPH is used here to demonstrate a speed used to transport
the sprayer, NOT as a service or field speed. Only the operator can deter-
mine the maximum safe operating speed of the sprayer.
NOTE
Maximum Solution Tank Capacity in Gallons at 8 MPH with 320/85R38 138A8/B Load Index Tires
Solution Weight Per Gallon 750 Gallon Tank 1000 Gallon Tank
Exceeding the weight capacity of the sprayer may
result in structural failure and will void the warranty.
IMPORT
ANT
Recommended tire pressure for 320/85R38 138A8/B Load Index Tires is 41 PSI at 8 MPH field speed.
